HFS-DO2
Digital Signal Converter
HFS-DO2 DIN-rail weighing-signal converter with a 0–20 mV input reference and RS485 communication.
- Nonlinearity
- ±0.3% FS
- Communication interface
- RS485
- Supply versions
- 12 V / 24 V
Supplied by WKSENSOR. Ask us about pricing, availability and delivery.
Product overview
The HFS-DO2 is a DIN-rail converter for weighing-signal acquisition and digital communication. The single-channel output configuration uses RS485; the pictured module identifies Modbus RTU and Free protocol references.
Weighing-signal conversion
A 0–20 mV input reference and RS485 digital communication in a DIN-rail enclosure. The front panel has a ZERO button and a DISP-labelled connector.
- Supply version
- 12 V or 24 V supply versions are offered. The pictured unit carries a 10–30 V DC supply reference.
- Digital interface
- RS485 communication with Modbus RTU or Free protocol references on the pictured unit.
Sensor-input terminals
Terminal legends run from left to right with the module upright.
- EXC+
- Excitation +
- EXC−
- Excitation −
- SHD
- Shield
- SIG+
- Signal +
- SIG−
- Signal −
- TEDS
- TEDS label
Technical reference
Specifications and options
| Parameter | Specification or option |
|---|---|
| Model | HFS-DO2 |
| Input reference | 0–20 mV |
| Communication interface | RS485 |
| Pictured protocol references | Modbus RTU / Free |
| Supply versions | 12 V / 24 V |
| Pictured unit supply | 10–30 V DC |
| Channel configuration | Single-channel output |
| Nonlinearity | ±0.3% FS |
| Operating temperature | −20–70 °C |
| Module protection | IP65 |
| Brand | WKSENSOR |
| Product reference | HH-809395681722 |
